Description
Specifications
ACCESSORIES
| Optional Kits | CXADTH1PMBZ Brushed Bronze CXADTH1PMCU Brushed Copper CXADTH1PMBT Brushed Black CXADTH1PMSS Brushed Stainless CXADTH1PMCG Brushed Brass CXADTH1PMFB Flat Black |
APPEARANCE
| Color Appearance | Stainless Steel |
| Door Appearance | Full-length flat door |
| Door Style | Long Door with Top Controls |
| Handle | Café™ |
| Handle Color | Brushed Stainless |
| Installation | Side Installation or Top Installation Included Built-Up Floor Capable Flush Cabinet Installation |
ECONOMICAL / QUIET
| Door Insulation | Insulation Mastic |
| Motor Type | Single Speed |
| Outer Wrap | Full-wrap Blanket Bitumen |
| Quiet Features | Quiet Water Valve Sealed Toe Kick Tub Collar Trim |
| Quiet Package | 45 dBA |
FEATURES
| Additional Protection | Active Flood Protect |
| Control Type | Top Controls Cap Touch Controls 12 Touchpads |
| Cutlery Tray | One piece removable 3rd rack |
| Dishwasher Control Features | Cycle Countdown with Bi-Color LED Status Light on door 1 “Clean” Light, 1 “Sanitized” Light Cycle Progress Indicators Last Cycle Memory Audible End-of-Cycle Signal |
| Dishwasher Cycles | Auto Pots Normal China Express |
| Dishwasher Drying Features | Multi-Wattage Wash & Dry Element Heated Dry – Ultra/On/Off Fan Assist Dry |
| Dishwasher Options | Delay Start 1-12 Hr. Start/Reset Bottle Jets Sabbath Mode Lock Controls Hi-Temp Wash Presoak + Sanitize (Certified to NSF Standard 184) Heated Dry Off Normal Dry Ultra Dry Wash Zone Upper Only Wash Zone Lower Only |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Exterior Style | Traditional |
| IsARViewEnabled | TRUE |
| Latch | Pull with Handle |
| Leveling System | 4 Leveling Legs |
| Lower Rack | Ball-Tip Tines 1/2 fixed tines, 1/2 fold down tines |
| Number of Cycles | 5 |
| Number of Options | 12 |
| Number of Place Settings | Up to 16 |
| OU Certified | No |
| Rack Color | Black Pearl |
| Rack Features | Ball-Tipped Tines Adjustable Upper Rack 3-Piece Silverware Basket with Cell Covers Full Extension Slides – Upper 2 short articulating plastic utility shelves w/Stemsafe and chop-stick slots |
| Racking Material | Nylon |
| Racking System | Full 3rd rack |
| Sabbath Mode | Yes |
| Sensor | Clean Sensor |
| Showroom Power Mode | Yes |
| Style | Built-In Top Control |
| Tub and Door Liner | Stainless Steel |
| Tub Type | Tall Tub |
| Upper Rack | Premium Height Adjustable Ball-Tip Tines 1/2 fixed tines, 1/2 fold down tines Fixed tines with Bottle Jets 1 Rack handle 2 Stem Safe Shelves Chop stick slots |
| Wash Arms | 3 Wash Levels Lower- Reversing Quad Blade Middle – Quad Blade Bottle Jets Deep Clean Silverware Jets |
| Wash System Features | Dual Pumps and Motors Bottle Jets (4) Automatic Temperature Control Drain Pump Hard Food Disposer with removable filter Reversing Quad Blade Lower Wash Arm Quad Blade Middle Wash Arm 90+ Spray Jet Wash System Deep Clean Silverware Jets Automatic HotStart |
| Wash System | 3-Level 800 Series |
| Water Filtration System | 100% Filtration with Hard Food Disposer and Removable Filter |
| WiFi Connect | Optional (Requires part no. PBX23W00Y0) |
POWER / RATINGS
| Calrod Heater Watts | 800/500 |
| Power Connection | Optional cord kit (GPFCORD – WX09X70910, WX09X70911) |
| Volts/Hertz/Amps | 120v; 60Hz; 7.2A |
WARRANTY
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
WEIGHTS & DIMENSIONS
| Approximate Shipping Weight | 118 lb |
| Cabinet Width | 24 in |
| Height w/ Legs Retracted – Minimum Height | 33 3/8 in |
| Height w/Legs Extended – Maximum Height | 34 5/8 in |
| Net Weight | 105 lb |
| Overall Depth | 24 in |
| Overall Depth with Handle | 26.30 in |
| Overall Height | 34 in |
| Overall Width | 23 3/4 in |
