Description
Specifications
ACCESSORIES
Optional Kits | CXADTH1PMBZ Brushed Bronze CXADTH1PMCU Brushed Copper CXADTH1PMBT Brushed Black CXADTH1PMSS Brushed Stainless CXADTH1PMCG Brushed Brass CXADTH1PMFB Flat Black |
APPEARANCE
Color Appearance | Stainless Steel |
Door Appearance | Full-length flat door |
Door Style | Long Door with Top Controls |
Handle | Café™ |
Handle Color | Brushed Stainless |
Installation | Side Installation or Top Installation Included Built-Up Floor Capable Flush Cabinet Installation |
ECONOMICAL / QUIET
Door Insulation | Insulation Mastic |
Motor Type | Single Speed |
Outer Wrap | Full-wrap Blanket Bitumen |
Quiet Features | Quiet Water Valve Sealed Toe Kick Tub Collar Trim |
Quiet Package | 45 dBA |
FEATURES
Additional Protection | Active Flood Protect |
Control Type | Top Controls Cap Touch Controls 12 Touchpads |
Cutlery Tray | One piece removable 3rd rack |
Dishwasher Control Features | Cycle Countdown with Bi-Color LED Status Light on door 1 “Clean” Light, 1 “Sanitized” Light Cycle Progress Indicators Last Cycle Memory Audible End-of-Cycle Signal |
Dishwasher Cycles | Auto Pots Normal China Express |
Dishwasher Drying Features | Multi-Wattage Wash & Dry Element Heated Dry – Ultra/On/Off Fan Assist Dry |
Dishwasher Options | Delay Start 1-12 Hr. Start/Reset Bottle Jets Sabbath Mode Lock Controls Hi-Temp Wash Presoak + Sanitize (Certified to NSF Standard 184) Heated Dry Off Normal Dry Ultra Dry Wash Zone Upper Only Wash Zone Lower Only |
Dispenser | Rinse Aid with Indicator and Adjustment |
Exterior Style | Traditional |
IsARViewEnabled | TRUE |
Latch | Pull with Handle |
Leveling System | 4 Leveling Legs |
Lower Rack | Ball-Tip Tines 1/2 fixed tines, 1/2 fold down tines |
Number of Cycles | 5 |
Number of Options | 12 |
Number of Place Settings | Up to 16 |
OU Certified | No |
Rack Color | Black Pearl |
Rack Features | Ball-Tipped Tines Adjustable Upper Rack 3-Piece Silverware Basket with Cell Covers Full Extension Slides – Upper 2 short articulating plastic utility shelves w/Stemsafe and chop-stick slots |
Racking Material | Nylon |
Racking System | Full 3rd rack |
Sabbath Mode | Yes |
Sensor | Clean Sensor |
Showroom Power Mode | Yes |
Style | Built-In Top Control |
Tub and Door Liner | Stainless Steel |
Tub Type | Tall Tub |
Upper Rack | Premium Height Adjustable Ball-Tip Tines 1/2 fixed tines, 1/2 fold down tines Fixed tines with Bottle Jets 1 Rack handle 2 Stem Safe Shelves Chop stick slots |
Wash Arms | 3 Wash Levels Lower- Reversing Quad Blade Middle – Quad Blade Bottle Jets Deep Clean Silverware Jets |
Wash System Features | Dual Pumps and Motors Bottle Jets (4) Automatic Temperature Control Drain Pump Hard Food Disposer with removable filter Reversing Quad Blade Lower Wash Arm Quad Blade Middle Wash Arm 90+ Spray Jet Wash System Deep Clean Silverware Jets Automatic HotStart |
Wash System | 3-Level 800 Series |
Water Filtration System | 100% Filtration with Hard Food Disposer and Removable Filter |
WiFi Connect | Optional (Requires part no. PBX23W00Y0) |
POWER / RATINGS
Calrod Heater Watts | 800/500 |
Power Connection | Optional cord kit (GPFCORD – WX09X70910, WX09X70911) |
Volts/Hertz/Amps | 120v; 60Hz; 7.2A |
WARRANTY
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
WEIGHTS & DIMENSIONS
Approximate Shipping Weight | 118 lb |
Cabinet Width | 24 in |
Height w/ Legs Retracted – Minimum Height | 33 3/8 in |
Height w/Legs Extended – Maximum Height | 34 5/8 in |
Net Weight | 105 lb |
Overall Depth | 24 in |
Overall Depth with Handle | 26.30 in |
Overall Height | 34 in |
Overall Width | 23 3/4 in |
